One of the ways to configure authentication between two Cisco ASA firewalls having a site-to-site IPSec VPN tunnel between them is to configure a pre-shared key under the tunnel group attributes. This is actually the most common implementation of IPSEC lan-to-lan authentication that you will find in most real life networks.

The pre-shared key must be the same on both IPSEC VPN devices between which the secure tunnel is created. To configure the pre-shared key on a Cisco ASA:

tunnel-group 1.1.1.1 type ipsec-l2l
tunnel-group 1.1.1.1 ipsec-attributes
pre-shared-key key123

Now, after configuring the pre-shared key, it is stored as encrypted hash on the ASA appliance and therefore when you view the running configuration (show run) you don’t see the actual clear text key anymore (i.e instead of “key123” you will see “*”).

Ciscoasa# show run

tunnel-group 1.1.1.1 type ipsec-l2l
tunnel-group 1.1.1.1 ipsec-attributes
pre-shared-key *

The problem arises when you forget the pre-shared key after a few months and you want to change one of the VPN tunnels. This situation happened to me recently when I had to change the public IP address on one of the ASA sites which had a Lan-to-Lan tunnel with a second ASA. Therefore I had to reconfigure the tunnel group and re-enter the old pre-shared key. However, I did not have it stored in clear text anywhere. The way to recover the pre-shared key is actually simple. Use the more system:running-config command. This command shows the pre-shared key in clear text format:

Ciscoasa# more system:running-config

…..
…..
tunnel-group 1.1.1.1 ipsec-attributes
pre-shared-key key123

Cisco ASA supports two major WebVPN modes: Clientless WebVPN and Anyconnect WebVPN.

Let’s see the differences between the two WebVPN modes and I’m sure you will understand why the AnyConnect mode is much better in my opinion.

Clientless WebVPN does not require any VPN client to be installed on user’s computer. It uses a normal web browser. By pointing the browser to https://[outside address of ASA] the user authenticates with the firewall and gets access to a Web Portal. Through this Web Portal, the user can then access a limited number of internal applications. Specifically, only internal Web applications (HTTP, HTTPs), email servers (POP3, SMTP, IMAP), Windows file shares and a small number of TCP legacy applications (e.g Telnet) can be accessed. That is, there is no full network connectivity with Clientless WebVPN.

AnyConnect WebVPN, on the other hand, provides FULL network connectivity to the remote user. The ASA firewall, working as AnyConnect WebVPN server, assigns an IP address to the remote user and attaches the user to the network. Thus, all IP protocols and applications function across the SSL VPN tunnel without any problems. For example, a remote user, after successfully authenticated with AnyConnect VPN, can open a Remote Desktop connection and access a Windows Terminal Server inside the central network. Although a special Java-based client is required to be installed on the user’s desktop, this client can be supplied dynamically to the user from the ASA. The user can connect with a browser to the ASA firewall and download the Java client on demand. The Java client can remain installed or even get removed from the user’s desktop when disconnected from the ASA appliance. This Java client is small in size (around 3MB) and is stored on the ASA flash memory.

The convenience and advantages of secure VPNs has driven the specific technology to keep evolving continuously. Several years ago we only had the standardized IPSec VPN (which still strongly exists today). IPSec is a pure IP network VPN technology for connecting distant LAN networks over unsecured paths. Also, IPSec is used for client VPNs connecting remote teleworkers to their central site network. The characteristic of IPSec VPNs is that it provides FULL network connectivity between the VPN peers. That is, a remote access client IPSec VPN will connect the remote user to the central network just like the user would be locally connected.

After IPsec, the Web SSL VPN made its appearance. The remote user needs just a Web Browser with HTTPs to connect to the central site network. After authentication, the user is presented with a Web portal with links to the applications he is allowed to run. That is, the Web SSL VPN does not provide full network visibility to the remote user. The user has access only to specific applications (like internal email, internal files etc). Both IPSec VPNs and SSL VPNs are supported by Cisco ASA 5500 firewalls.

The newest generation of remote access VPNs is offered from Cisco AnyConnect SSL VPN client. This is supported by Cisco ASA 8.x. The AnyConnect SSL VPN provides the best features from both of the other VPN technologies (IPSec and Web SSL). With AnyConnect, the remote user has full network connectivity to the central site. Also, it offers the convenience of the Web SSL since there is no need to install an IPSec VPN client permanently to the user’s computer. Instead, there is an SSL client stored in the ASA flash memory which is downloaded to the remote user’s computer on demand.

How AnyConnect SSL VPN Client works

For first time user connection, the remote teleworker just opens a browser pointing to https://<ASA-outside-public-IP>. The browser connects to the ASA firewall and presents the user with a login screen. The user enters his credentials (username/password) and the ASA identifies that the user does not have the SSL client installed. Therefore it pushes the SSL client to the user’s computer. The client installs itself to the remote PC and establishes a secure SSL VPN connection between the remote user and the ASA. The user is also assigned an IP address from an address pool configured on the ASA and has full network access to the central site. When the SSL connection is stopped, the SSL client either uninstalls itself or remains on the user’s PC (depending on the configuration of the ASA).

In the case of a previously installed client, when the user authenticates, the security appliance examines the revision of the client, and upgrades the client as necessary.

The AnyConnect SSL client can be downloaded from the security appliance, or it can be installed manually on the remote PC by the system administrator.

In another post I will explain how to configure the AnyConnect SSL VPN on a Cisco ASA 5500 firewall.
